Calculations
The calculations feature is a self-service tool designed for both overall circuitry and individual component assessments. It empowers new-to-industry designers by providing an interactive guide that facilitates decision-making without requiring manual assistance.
Based on the output metric, the user can choose the appropriate component from the 10k+ assets available in the component marketplace.
The different types are
Circuitry / Switchgear Calculation
Helps decide MCCB, RCB, and relays based on power output.
Motor / Drive
Selects motor types and associated drives for applications.
PLC Based
Outputs related to I/O lists and additional modules.
Safety and Associated Elements
Finalizes safety push buttons, light curtains, and gears.
WHY DO YOU NEED THE CALCULATIONS FEATURE?
The calculations feature offers several benefits:
Standardised Method
Provides a standardised approach to accurately calculate and select critical components.
Minimises Rework
Reduces the need for rework and redesign, ensuring projects are delivered within timelines.
Component Recommendations
Recommends suitable components based on the calculated outputs, optimising design decisions.
HOW IT WORKS?
Explore our calculations feature with these easy steps :
Input Requirements
Begin by sharing your BOM inputs related to the application for accurate outputs. Alternatively, select individual components for specific calculation types instead of sharing a predefined BOM.
STEP
01
Choose Calculation Types
Select from the listed calculation types mentioned above.
STEP
02
Link to Component Marketplace
Once the output is displayed, seamlessly link to the component marketplace for efficient selection.
STEP
03
